Kodak DirectView CR 825 - Power Distribution; Overview

THEORY GUIDE Power Distribution
10DEC05
TG4825-1
Page
105 of 120
Section 10: Power Distribution
Overview
The Power Distribution subsystem includes:
• POWER SUPPLY
• Power Distribution
• INTERLOCK
• UNINTERRUPTIBLE POWER SUPPLY (UPS)
BOARD A18
- LASER DRIVER
PRE-REGULATOR
INTERLOCK control for:
- DUPLEX CAM
- CASSETTE DRIVE MOTOR
- SSC BOARD A6
- GALVO BOARD A4
- LASER DIODE DRIVER
BOARD A17
- ERASE LAMPS
MSC
BOARD
A1
LAMPS
ERASE
K1 RELAY
PS1
POWER
SUPPLY
+24 V DC
-24 V DC
120 V AC
INTERLOCK
control
signal
120 V AC
UPS1
120 V AC
TRANSFORMER
90 - 264 V AC
T1
PC
INTERNAL
120 V AC
INTERLOCK
FRONT DOOR
SWITCH
+12 V DC
+24 V DC
-24 V DC
DC power to
and MOTORS
all BOARDS
