EXTRACTION BAR
The EXTRACTION BAR holds the PLATE when it moves down during scanning and up after
erasing.
Note
The PLATE is not visible in the graphic.
H194_5015GC
EXTRACTION BAR
position-fixed
Erase position
position
Start of
scan position
position
Reference
Home position
H194_5015GCB
End of scan
