1-2 8F2927 January 17, 2007
Overview
2 Film registration. The film registration orients and centers the film
while moving the film from the film drawers to the imaging portion of
the Imager.
3 Film imaging. The optics module writes the image onto the film
while the film is moved through the exposure transport.
4 Film processor. The film processor uses heat to develop the image
written onto the film by the laser in the optics module.
5 Densitometer. The densitometer receives the film after it passes
through the processor and performs a density check to confirm image
quality.
6 Film sorter. Your Imager may be configured without a sorter. The
film sorter receives the processed film and transports the film to the
selected film bin on top of the Laser Imager. The first bin holds 125
sheets of film. Each of the other four bins holds 50 sheets of film.
7 Local panel. The local panel contains the power button used to turn
power ON/OFF for the Imager during normal operations. It also
contains the touch screen.
8 Touch screen. The touch screen is your interface to the Laser
Imager. The screen accepts your commands and gives you status
information about Imager functions.
