Component Testing and Adjustment 7-17TP-5606 6/02
Component
Ohmmeter
Connections
Remarks Results
P1 ground
connection
P1-9 and ground Ohmmeter on R x 1 scale. If good--zero ohms
(continuity). Any other
reading indicates a poor
ground connection.
Low oil pressure
(LOP) safety
shutdown switch
P1-15 and engine block
(ground)
NOTE: J4 and P4 must be
connected to perform this
test.
Ohmmeter on R x 1 scale.
This test is not conclusive
until the temperature
shutdown switches are
checked.
If good--zero ohms
(continuity). Then, disconnect
LOP switch lead and isolate
terminal. Meter reading
reading should show an open
circuit.
High water
temperature
(HWT) safety
shutdown switch
P1-15 and engine block
(ground)
NOTE: LOP switch lead
should be removed and
isolated.
NOTE: J4 and P4 must be
connected to perform this
test.
Ohmmeter on R x 1 scale. If good-- open circuit. Any
continuity suggests that
temperature switch(es) are
defective. Disconnect
individual leads to determine
which switch is defective.
Rotor See separate paragraph with
same title.
See separate paragraph with
same title.
See separate paragraph with
same title.
Stator See separate paragraph with
same title.
See separate paragraph with
same title.
See separate paragraph with
same title.
Exciter Field See separate paragraph with
same title.
See separate paragraph with
same title.
See separate paragraph with
same title.
Exciter Armature See separate paragraph with
same title.
See separate paragraph with
same title.
See separate paragraph with
same title.
Fuel Solenoid See separate paragraph with
same title.
See separate paragraph with
same title.
See separate paragraph with
same title.
Figure 7-13. Engine/Generator Set Component Testing with Ohmmeter (Sheet 2 of 2)
