TORQUE SPECIFICATIONS
3,5
CV940 CV960 CV980 CV1000
Cylinder Head
Fastener (torque in 2 increments)
Head Bolt fi rst to 22.6 N·m (200 in. lb.)
fi nally to 45.2 N·m (400 in. lb.)
Pipe Plug 3/4 in. 28.25 N·m (250 in. lb.)
Rocker Arm Stud (AVT) 11.3 N·m (100 in. lb.)
Setscrew, AVT pivot locking 7.3 N·m (65 in. lb.)
Debris Screen
Hex Stud 9.9 N·m (88 in. lb.)
Mounting Screw 9.9 N·m (88 in. lb.)
Flywheel
Fan Fastener 9.9 N·m (88 in. lb.)
Retaining Screw 67.8 N·m (50 ft. lb.)
Fuel Pump
Screw 8.0-12.1 N·m (71-107 in. lb.) into new holes
6.0-9.0 N·m (53-80 in. lb.) into used holes
Governor
Lever Nut 7.3 N·m (65 in. lb.)
Yoke Mounting Screw 2.2 N·m (20 in. lb.)
Ignition
Spark Plug 27 N·m (20 ft. lb.)
Module Fastener 6.2 N·m (55 in. lb.) into new holes
4.0 N·m (35 in. lb.) into used holes
Rectifi er-Regulator Fastener 2.0 N·m (18 in. lb.)
Lifter Feed Chamber Cover
Screw 6.2 N·m (55 in. lb.) into new holes
4.0 N·m (35 in. lb.) into used holes
Muffl er
Retaining Nut 24.4 N·m (216 in. lb.)
Screw, intermittent bracket (into weld nut) 13.5 N·m (120 in. lb.)
Oil Cooler
Mounting Screw 2.2 N·m (20 in. lb.)
Oil Filter Adapter/Housing
Mounting Screw 24.4 N·m (216 in. lb.)
Oil Filter Nipple 18 N·m (159 in. lb.)
Oil Pan
Fastener 27 N·m (238 in. lb.)
Oil Pickup Tube
Mounting Screw 10.7 N·m (95 in. lb.) into a new hole
7.3 N·m(65 in. lb.) into a used hole
3
Values are in Metric units. Values in parentheses are English equivalents.
5
Lubricate threads with engine oil prior to assembly.
