TP-6126 8/02 33Section 4 Operation
LED Indicators
Loaded Exercise
N
Available
N
Position
OFF
Position
E
Available
E
Position
Load
Control
Exercise
(flashing)
Preferred-to-Standby Time Delay X X X X
Pre-Transfer to Standby Load Control X X X X X
Off-to-Standby Time Delay
(programmed-transition only)
X X X X
In-Phase Synch (as programmed;
N/A for programmed-transition models.)
X X
(flashing)
X X
Post-Transfer to Standby Load Control X X X X X
Pre-Transfer to Preferred Load Control X X X X X
Off-to-Preferred Time Delay
(programmed-transition only)
X X X X
Post-Transfer to Preferred Load Control X X X X X
Engine Cooldown Time Delay
(Default = 0)
X X X X
Figure 4 -11 User Interface LED Indicators During a Loaded Exercise
