TP-6126 8/0256 Section 6 Accessories
6.8.4 Battery Charger Specifications
Figure 6-28 lists the battery charger specifications.
Output
Charging 12VoltsDC(min.)at6Amps
24VoltsDC(min.)at3Amps
Maintaining 13.30 Volts DC at 0.1 Amps
Input
Rated AC Voltage 208 VAC, AC connector pin 2
240 VAC, AC connector pin 4
480 VAC, AC connector pin 6
600VAC, AC connector pin 9
Current Draw @ 50/ 60 Hz, 0.7 Amps Maximum
Maximum Recommended Battery Size
Recharging 150 Amp--Hours
Maintenance only 300 Amp--Hours
Physical Dimensions
Height 3.5 in. (8.9 cm.)
Width 6.4 in. (16.3 cm.)
Depth 2.1 in. (5.3 cm.)
Weight 3.5 lb. (1.6 kg)
Figure 6 -28 Battery Charger Specifications
