Maintenance
Generic maintenance activities
Fig. 53: Replacing tensioning device
1
Tensioning device 2 Screw (M10)
Removing tensioning device
u Remove screw (M10) 2.
u Remove tensioning device 1.
Installing tensioning device
u Install tensioning device 1 with screw (M10) 2.
u Tighten screw (M10) 2 to standard torque.
Information
Install battery charging alternator cover in reverse sequence. (For more information see:
5.8.1 Removing the battery charging alternator cover, page 106.) .
110
© 2022 by Kohler Co. All rights reserved.
KD62V12 33521030301_8_1 EN_US 2022-09
