Maintenance
Generic maintenance activities
u Release and remove ratchet wrench.
w
The tensioning device is released.
Fig. 52: Checking drive belt tension — Measurement area
1
Sensor 2 Belt section
u Check tension with frequency meter. The measured frequency value must be 165 Hz (Min 149
Hz - Max 182 Hz).
In case of air conditioning compressor installed, proceed in the same way.
Information
Install battery charging alternator cover in reverse sequence. (For more information see:
5.8.1 Removing the battery charging alternator cover, page 106.)
5.8.4 Replacing tensioning device — SL110
q Battery charging alternator cover is removed. (For more information see: 5.8.1 Removing the
battery charging alternator cover, page 106.)
q Drive belt is removed. (For more information see: 5.8.3 Replacing drive belt — SL 109,
page 108.)
q New tensioning device is available.
KD62V12 33521030301_8_1 EN_US 2022-09
© 2022 by Kohler Co. All rights reserved.
109
