Kohler KD62V12

Maintenance
Air system
5.12 Air system
5.12.1 Checking service indicator on air filter — SL006
Refer to the generator set manual for more details.
5.12.2 Replacing crankcase breather — SL107
Fig. 79: Crankcase ventilation
1
Screw (M10) 3 Seal
2 Filter element
Information
Actual number and location of crankcase breather filters may depend on application set.
Removal
u Remove screws 1.
u Remove filter element 2.
u Remove seal 3.
Installation
u Screw filter element 2 with screws 1 and seal 3.
134
© 2022 by Kohler Co. All rights reserved.
KD62V12 33521030301_8_1 EN_US 2022-09
