Maintenance
Exhaust gas aftertreatmen
t system (depending on configur
ation)
Fig. 82: Removing the heating mat scr
ews
u
Remove the heating mat scr
ews (M6).
Fig. 83: Removing the heating mat
u
Remove the heating mat fr
om the filter
.
KD62V12 33521030301_8_1 EN_US 2022-09
© 2022 by Kohler Co. All righ
ts reserved.
137
