6
INFORMATION ABOUT REPLACEMENTS
EN 48
6.2 Oil filter cartridge replacement
•
Before proceeding with operation,
read Par. 3.2.2
Warning
•
Electric/pneumatic screwdrivers are
forbidden.
•
In case of low use replace il 12 months.
•
For disposal of oil filter cartridge and fuel
filter refer to
Par. 6.6 DISPOSAL and
SCRAPPING .
1.
Unscrew cartridge holder cover A by
performing three complete turns and wait
1 minute..
NOTE
: this operation allows to oil contained in
the support
F
to flow into the oil sump in the
correct way.
1.
Unscrew cartridge holder cover A and
check that the oil in the lub. oil filter
support F has flowed towards the oil
sump.
2.
Remove the cap A as well as the oil
cartridge B from the oil filter support.
Fig 6.5
1.
Remove and replace the oil cartridge B
with a new one.
Remove and replace the gaskets C, D
and E with new ones.
