SAFETY INFORMATION
3
17
EN
Internal Communication: For internal & partner use only.
Important
• Only use the eyebolts A installed by KOHLER to move the engine (Fig. 3.1).
• The angle between each lifting chain and the eyebolts shall not exceed 15° inwards.
• The correct tightening of the lifting screws is 25Nm.
• Do not interpose spacers or washers between the eyebolts and engine head.
• Provided that the above requirements are met, if the lifting eyebolts are subject to permanent
deformation (inwards), all subsequent lifting operations must be performed in order to prevent them
from bending in the opposite direction.
Fig 3.1
