5
INFORMATION ABOUT MAINTENANCE
EN 32
5.7 Rubber hoses check
•
For safety precautions see Chap. 3.
The check is carried out by exerting a slight deflection or
bending along the pipe and near the hose clamps.
Components must be replaced if they have clear signs of
cracks, tears, cuts, leaks and do not retain a certain degree of
elasticity.
Important
•
Before proceeding with operation, read Par. 3.2.2.
•
If hoses are damaged contact an authorized KOHLER
workshop.
Fig 5.7
Loosen the capscrews
and remove guard
.
2.
Check that the:
•
Fuel system hoses A are intact.
•
Hoses for the cooling circuit B1 and B2. To access
the control of the cooling hoses B1 unscrew the
four screws E and remove the safe guard F.
•
Vent system pipes C.
•
Air system ducts D.
•
When the control is finished the safe guard F mount
and tighten the screws E.
