INFORMATION ABOUT USE
4
27
EN
Internal Communication: For internal & partner use only.
NOTE: Before proceeding with any operation on the engine,
stop it and allow it to cool.
Warning
•
Presence of steam pressurized coolant danger of
burns.
1.
Loosen the cap A and fill the radiator with coolant
composed of:
50% ANTIFREEZE and 50% decalcified water.
2.
Top liquid up until the pipes inside the radiator are
covered by about 5 mm. Do not overfill the radiator,
but leave room for the coolant to expand.
3.
For engines equipped with expansion tank, pour in
fluid until reaching the max level mark.
4.
Loosen the screw C , release any air and tighten the
screw C (Tightening torque of 8 Nm - Fig. 4.5).
5.
Re-tighten the cap A .
6.
After a few hours of operator, stop the engine and
allow the liquid to cool returns to a ambient
temperature and check the coolant level again.
Fig. 4.3
Fig. 4.4
Fig. 4.5
NOTE: Click on the right to play the procedure.
https://youtu.be/XuR1tlU2zmo
