6.4 Approvals
6.4.1 Conformance with UL/cUL
This servo amplifier is listed under UL file number E217428.
UL (cUL)-certified servo amplifiers (Underwriters Laboratories Inc.) fulfil the relevant U.S. and Canadian stand-
ard (in this case UL 840 and UL 508C). The technical conformance with the U.S. and Canadian standard is
determined by an independent UL (cUL) inspector through the type testing and regular check-ups. Apart from the
notes on installation and safety in the documentation, the customer does not have to observe any other points in
direct connection with the UL (cUL)-certification of the equipment.
UL 508C: UL 508C describes the fulfillment by design of minimum requirements for electrically operated power
conversion equipment, such as frequency converters and servo amplifiers, which is intended to eliminate the risk
of fire being caused by such equipment.
UL 840: UL 840 describes the fulfillment by design of air and insulation creepage spacings for electrical equip-
ment and printed circuit boards.
Markings Marquages
Use 60°C or 75°C copper wire only.
Use Class 1 wire only.
Tightening torque for field wiring terminals.
S701...724: X0, X8, X9: 6.20 to 7.08 lbf in.
S748...772: X0, X8: 8-2 AWG, 40 lbf in.
Use in a pollution degree 2 environment.
These devices provide solid state motor
overload protection at 130% of full load cur-
rent.
Integral solid state short circuit protection
does not provide branch circuit protection.
Branch circuit protection must be provided
in accordance with the National Electrical
Code and any additional local codes.
These devices are not provided with motor
over-temperature sensing.
Suitable for use on a circuit capable of deliv-
ering not more than 42kA rms symmetrical
amperes for a max. voltage of 480 Vac.
S701...724: The drives may be connected
together via the “common bus” (DC bus link)
based on the instructions given in the
Instructions Manual. The devices may also
be grouped from the AC input side based on
the max. input fuse.
S748/772: For use on a solidly grounded
wye source only.
Utilisez un fil en cuivre 60°C ou 75 °C.
Utilisez seulement un fil de classe 1.
Couples de serrage recommandée
S701...724: X0, X8, X9: 6.20 to 7.08 lbf in.
S748...772: X0, X8: 8-2 AWG, 40 lbf in.
Utilisation dans un environnement de pollution de niveau
2.
Ces variateurs offrent une protection contre les sur-
charges de moteur à semi-conducteur à 130 % du cour-
ant FLA nominal.
Une protection de court-circuit à semi-conducteur inté-
grale ne fournit pas de protection de la dérivation. Il con-
vient de garantir une protection de la dérivation
conforme au NEC (National Electrical Code) et aux
réglementations locales en vigueur, ou aux directives
équivalentes applicables.
Ces variateurs n’offrent pas de capteurs de température
excessive.
Ce produit est conçu pour une utilisation sur un circuit
capable de fournir 42 000 ampères symétriques (rms)
maximum pour 480V.
S701...724: Les variateurs peuvent être reliés entre eux
via le “bus commun CC” sur la base des instructions du
Manuel d'Instructions. Les variateurs peuvent être
groupés d'entrée AC basé sur le max. fusible d’entrée.
S748/772: Pour une utilisation sur une source en étoile
solidement à la terre.
Supply circuit protection:
Model Fuse Class Rating Max.Fuse Rating
S7010 RK5, CC, J, T 600VAC 200kA 6A (Time-Delay)
S7030 RK5, CC, J, T 600VAC 200kA 6A (Time-Delay)
S7060 RK5, CC, J, T 600VAC 200kA 6A (Time-Delay)
S7100 RK5, CC, J, T 600VAC 200kA 6A (Time-Delay)
S7240 RK5, CC, J, T 600VAC 200kA 6A (Time-Delay)
S7480 RK5, CC, J, T 600VAC 200kA 60A (Time-Delay)
S7720 RK5, CC, J, T 600VAC 200kA 80A (Time-Delay)
