S700 Safety Guide | 2 English
2.2.3 Prohibited Use
Other use than that described in chapter “Use as directed” is not intended and can lead to per-
sonnel injuries and equipment damage.
The use of the servo amplifier in the following environments is prohibited:
potentially explosive areas,
environments with corrosive and/or electrically conductive acids, alkaline solutions, oils,
vapors, dusts,
directly on non-grounded supply networks or on asymmetrically grounded supplies with a
voltage >240V,
ships or offshore applications.
Commissioning the servo amplifier is prohibited if the machine in which it was installed,
does not meet the requirements of the EC Machinery Directive,
does not comply with the EMC Directive or with the Low Voltage Directive,
does not comply with any national directives.
The control of holding brakes by the S700 alone may not be used in applications, where func-
tional safety is to be ensured with the brake.
2.2.4 Transport
Only by qualified personnel in the manufacturer’s original recyclable packaging
Avoid shocks
Temperature: –25 to +70°C, max. 20K/h rate of change, class 2K3 acc. to EN61800-2
Humidity: max. 95% relative humidity, no condensation, class 2K3 acc. to EN61800-2
If the packaging is damaged, check the unit for visible damage. In this case, inform the
shipper and the manufacturer.
The servo amplifiers contain electrostatically sensitive components which can be damaged
by incorrect handling. Discharge yourself before touching the servo amplifier. Avoid contact
with highly insulating materials (artificial fabrics, plastic films etc.). Place the servo amplifier
on a conductive surface.
2.2.5 Packaging
The S700 packaging consists of recyclable cardboard with inserts.
Dimensions S701...S712: (HxWxD) 125x415x350 mm
Dimensions S724: (HxWxD) 155x415x350 mm
Dimensions S748/S772: (HxWxD) 390x600x400 mm
Labeling : nameplate outside at the box
2.2.6 Storage
Storage only in the manufacturer’s original recyclable packaging
Max. stacking height S701...S724: 8 cartons
Max. stacking height S748...S772: 3 cartons
Storage temperature: -25 to +55°C, max. rate of change 20K/h, class 1K4 acc. to
EN61800-2
Storage humidity: 5 ... 95% relative humidity, no condensation, class 1K3 acc. to
EN61800-2
Storage duration: Less than 1 year without restriction.
More than 1 year: capacitors must be re-formed before setting up and operating the servo
amplifier. To do this, remove all electrical connections and apply single-phase 230V AC
for about 30 minutes to the terminals L1 / L2.
48 Kollmorgen | September 2015
