Kollmorgen SERVOSTAR 300

7.4 Mains filters 1NF-10...12
Observe the safety instructions ➜ p. 28.
For single-phase operation only.
Technical Data
Type
Nominal
Current
[A]*
Nominal
Voltage
[V]
A
[mm]
B
[mm]
C
[mm]
D
[mm]
F
[mm]
M
[mm]
N
[mm]
P
[mm]
Weight
[kg]
Connec-
tion
1NF-10 10 230 85 49 40.3 54 75 5.3 6.3 87 0.29 Fast-on
1NF-12 12 230 156 57.5 45.4 130.5 143 5.3 6 156 0.73 Fast-on
* at 40°C environment temperature
Accessories Europe | 7 Mains filters
Kollmorgen | December 2014 29
