Accessories Europe | 7 Mains filters
7.5 Mains filters 1NF-20B, 1NF-25
Observe the safety instructions ➜ p. 28.
For single-phase operation only.
Technical Data
Nominal Voltage
Type Nominal
Current [A]*
IEC UL/CSA Weight
[kg]
Connection Phase
Terminals
Connection PE
1NF-20B 20 230V 125V 0.93
Wires up to 4mm²
Torque 0.6 to 0.8 Nm
Bolt M 6
Torque 3.5 to 4 Nm
1NF-25 25 230V 230V 0.7
Wires up to 10mm²
Torque 1.5 to1.8 Nm
* at 50°C environment temperature
30 Kollmorgen | December 2014
