6 PC800, 850-8
SEN00791-02 40 Troubleshooting
Failure code [CA451] Rail Press Sensor High Error
Action code Failure code
Trouble
Rail Press Sensor High Error
(Engine controller system)
E11 CA451
Contents of
trouble
• High pressure error occurred in common rail pressure sensor circuit.
Action of
controller
• Limits output and continues operation (limits common rail pressure).
Problem that
appears on
machine
• Engine output lowers.
Related
information
• The signal voltage of the common rail pressure sensor can be checked with the monitoring function
(Code: 36401 Common rail pressure sensor voltage).
Possible causes
and standard
value in normal
state
Cause Standard value in normal state/Remarks on troubleshooting
1
Defective sensor power
supply system
If failure code [CA352] or [CA386] is displayed, carry out troubleshoot-
ing for it first.
2
Defective common rail
pressure sensor
(Internal defect)
aPrepare with starting switch OFF, then turn starting switch ON or start
engine and carry out troubleshooting.
PFUEL Voltage
Between (1) – (3) Power supply 4.75 – 5.25 V
Between (2) – (3) Signal 0.25 – 4.6 V
Sensor voltage is measured with wiring harness connected. Accord-
ingly, if voltage is abnormal, check wiring harness and controller, too, for
another cause of trouble, and then judge.
3
Disconnection in wiring har-
ness
(Disconnection in wiring or
defective contact in con-
nector)
aPrepare with starting switch OFF, then carry out troubleshooting with-
out turning starting switch ON.
Wiring harness between ENG (female) (33) –
PFUEL (female) (1)
Resis-
tance
Max. 1 z
Wiring harness between ENG (female) (25) –
PFUEL (female) (2)
Resis-
tance
Max. 1 z
Wiring harness between ENG (female) (47) –
PFUEL (female) (3)
Resis-
tance
Max. 1 z
4
Ground fault in wiring har-
ness
(Short circuit with GND cir-
cuit)
aPrepare with starting switch OFF, then carry out troubleshooting with-
out turning starting switch ON.
Wiring harness between ENG (female) (33) –
PFUEL (female) (1) and chassis ground
Resis-
tance
Min. 1 Mz
Wiring harness between ENG (female) (25) –
PFUEL (female) (2) and chassis ground
Resis-
tance
Min. 1 Mz
Wiring harness between ENG (female) (47) –
PFUEL (female) (3) and chassis ground
Resis-
tance
Min. 1 Mz
5
Short circuit in wiring har-
ness
(with another wiring har-
ness)
aPrepare with starting switch OFF, then carry out troubleshooting with-
out turning starting switch ON.
Wiring harness between ENG (female) (33) –
PFUEL (female) (1) and between ENG
(female) (25) – PFUEL (female) (2)
Resis-
tance
Min. 1 Mz
Wiring harness between ENG (female) (33) –
PFUEL (female) (1) and between ENG
(female) (47) – PFUEL (female) (3)
Resis-
tance
Min. 1 Mz
Wiring harness between ENG (female) (25) –
PFUEL (female) (2) and between ENG
(female) (47) – PFUEL (female) (3)
Resis-
tance
Min. 1 Mz
To Next Page
