42 PC800, 850-8
SEN00791-02 40 Troubleshooting
Failure code [CA2271] EGR Valve Pos Sens High Error
Action code Failure code
Trouble
EGR Valve Pos Sens High Error
(Engine controller system)
E11 CA2271
Contents of
trouble
• High error occurred in EGR valve lift sensor circuit.
Action of
controller
• Limits output and continues operation.
• Close EGR and bypass valves.
Problem that
appears on
machine
• Engine output lowers.
Related
information
• Signal voltage of EGR valve position sensor can be checked with monitoring function.
(Code: 18101 EGR valve position sensor voltage)
Possible causes
and standard
value in normal
state
Cause Standard value in normal state/Remarks on troubleshooting
1
Defective sensor power
supply system
If failure code [CA187] or [CA227] is displayed, carry out troubleshoot-
ing for it first.
2
Defective EGR valve lift sen-
sor
(Internal defect)
aPrepare with starting switch OFF, then turn starting switch ON or start
engine and carry out troubleshooting.
SEGR Voltage
Between (1) – (2) Power supply 4.75 – 5.25 V
Sensor voltage is measured with wiring harness connected. Accord-
ingly, if voltage is abnormal, check wiring harness and controller, too, for
another cause of trouble, and then judge.
3
Disconnection in wiring har-
ness
(Disconnection in wiring or
defective contact in con-
nector)
aPrepare with starting switch OFF, then carry out troubleshooting with-
out turning starting switch ON.
Wiring harness between ENG (female) (37) –
SEGR (female) (1)
Resis-
tance
Max. 1 z
Wiring harness between ENG (female) (47) –
SEGR (female) (2)
Resis-
tance
Max. 1 z
Wiring harness between ENG (female) (19) –
SEGR (female) (3), (4)
Resis-
tance
Max. 1 z
4
Ground fault in wiring har-
ness
(Short circuit with GND cir-
cuit)
aPrepare with starting switch OFF, then carry out troubleshooting with-
out turning starting switch ON.
Wiring harness between ENG (female) (37) –
SEGR (female) (1) and chassis ground
Resis-
tance
Min. 1 Mz
Wiring harness between ENG (female) (47) –
SEGR (female) (2) and chassis ground
Resis-
tance
Min. 1 Mz
Wiring harness between ENG (female) (19) –
SEGR (female) (3), (4) and chassis ground
Resis-
tance
Min. 1 Mz
5
Short circuit in wiring har-
ness
(with another wiring har-
ness)
aPrepare with starting switch OFF, then carry out troubleshooting with-
out turning starting switch ON.
Wiring harness between ENG (female) (37) –
SEGR (female) (1) and between ENG (female)
(47) – SEGR (female) (2)
Resis-
tance
Min. 1 Mz
Wiring harness between ENG (female) (37) –
SEGR (female) (1) and between ENG (female)
(19) – SEGR (female) (3), (4)
Resis-
tance
Min. 1 Mz
Wiring harness between ENG (female) (47) –
SEGR (female) (2) and between ENG (female)
(19) – SEGR (female) (3), (4)
Resis-
tance
Min. 1 Mz
6 Defective engine controller
aPrepare with starting switch OFF, then turn starting switch ON or start
engine and carry out troubleshooting.
ENG Voltage
Between (37) – (47) 4.75 – 5.25 V
To Next Page
