14
5-1 PCB start-up check (self test)
5 PCB settings
When the power switch is turned ON after installation of machine, the performance of
game Printed Circuit Boards (PCB) is checked automatically and the result is
displayed on the screen. If the power is not turned ON, make sure that the main
power switch and sub-power switch are both at the ON position. (See pages 24 and 25)
•Be sure to check the PCB unit (self test) before using the machine.
•When the machine has been set up or moved to another place, turn ON
the power switch and press the demagnetizing button on the service panel
to demagnetize the monitor. If the monitor is still magnetized, the gun
unit may respond well or the target points may get out of position.
•When the machine has been set up or the PCB unit or the gun unit has
been repaired or replaced, be sure to position the target points, referring
to “CALIBRATION” on page 22.
•When the settings have been brought back to the factory ones, be sure to
position the target points, referring to “CALIBRATION” on page 22.
•If an abnormality persists or the machine does not operate properly,
immediately turn OFF the main power switch, unplug the power cord from
the receptacle and contact your nearest dealer.
Result of test
·The machine goes to the game mode and the demonstration game gets started.
If test is OK
· “BAD” appears on the screen, and the checking is repeated.
If “BAD” appears on the “RTC CHECK” or “EEP ROM CHECK” screen, once
turn OFF the power switch and turn it ON again while holding down the test
button on the service panel.
(The settings made in the manual test will return to the factory settings.)
If an abnormal display continues or the machine does not operate normally,
immediately turn OFF the main power switch, unplug the power cord and
contact your nearest dealer.
If any abnormality is detected
To Next Page
