Konami Mocap Boxing - User Manual

Questions and Answers

T
Tonya GarciaAug 19, 2025
How to fix no image and fluorescent light failure on Konami Mocap Boxing Arcade Game Machines?
- L
  lisa53Aug 19, 2025
  If there is no image on the screen and the fluorescent light doesn't light up on your Konami Arcade Game Machine, the possible causes are: the main power switch is OFF, the power cord is disconnected from the machine or wall outlet, the back door is open or loosely closed, or a circuit protector has been activated. To solve this, turn ON the power switch and check the shop's circuit breaker. Reconnect the power cord tightly and ensure the back door is screwed down tightly. If a circuit protector has been activated, take appropriate measures.
T
tonyahernandezAug 21, 2025
Why is there no sound or the sound is too loud on my Konami Mocap Boxing Arcade Game Machines?
- J
  John SalazarAug 21, 2025
  If there is no sound or the sound is too loud or soft on your Konami Arcade Game Machine, it could be due to the sound level being maladjusted or the connectors of the speakers being disconnected. To fix this, make the proper settings on the 'SOUND OPTIONS' screen and check the connectors for poor contact.
J
Joann RodriguezAug 23, 2025
What to do if the coin selector is malfunctioning on Konami Mocap Boxing Arcade Game Machines?
- M
  Marc HarperAug 23, 2025
  If the coin selector is malfunctioning on your Konami Arcade Game Machine, the coin selector itself may be defective. To address this, check the performance on the 'I/O CHECK' screen. If it is still malfunctioning, replace the coin selector or microswitch with a new one.
C
Christine HernandezAug 26, 2025
Why is there no image on the screen but the fluorescent light is on in Konami Arcade Game Machines?
- M
  Mr. Aaron StoneAug 26, 2025
  If there is no image on the screen but the fluorescent light is on for your Konami Arcade Game Machine, the memory card may not be inserted, the PC6 unit may be defective, or the monitor may be defective. Check the memory card for wrong position. Immediately turn OFF the main power switch, unplug the power cord from the receptacle and contact your nearest dealer.
J
Jessica MillerAug 27, 2025
How to fix a malfunctioning start or select button on Konami Mocap Boxing Arcade Game Machines?
- J
  Jeremy NelsonAug 27, 2025
  If the start or select button is malfunctioning on your Konami Arcade Game Machine, the switch wires may be disconnected from the start button, or the start button itself may be defective. Reconnect the switch wires to the socket. If that doesn't work, replace the start button with a new one.
W
william67Aug 29, 2025
How to adjust screen brightness on Konami Mocap Boxing?
- B
  bkellyAug 29, 2025
  If the screen is too dark or too bright on your Konami Arcade Game Machine, the monitor may be maladjusted. Readjust the brightness on the monitor adjustment PCB.
T
tammy49Sep 1, 2025
What does it mean if 'POSITION SENSOR BAD' appears on Konami Arcade Game Machines?
- D
  dianajordanSep 1, 2025
  If the sensor does not react or reacts abnormally and “POSITION SENSOR BAD” appears on your Konami Arcade Game Machine, the sensor lead wire may be removed, the sensor may be covered, or there may be trouble with the sensor. Check if the connector is connected correctly between the sensor frame and the monitor cabinet. Check whether the sensor mounted at three positions is hindered. Check the sensor action in 'I/O CHECK' mode. If the sensor is found troubled, turn OFF the main power switch, unplug the power cord and contact your nearest dealer.
M
Matthew HannaSep 3, 2025
How to fix fluorescent light failure on Konami Mocap Boxing Arcade Game Machines?
- A
  Anthony RamirezSep 3, 2025
  If the fluorescent light fails to light up on your Konami Arcade Game Machine, the fluorescent light or starter may be broken. Replace the fluorescent light or starter with a new one of the same type.
D
Danielle WintersSep 5, 2025
Why is the button functioning but not lighting up on Konami Mocap Boxing?
- C
  Christina SmithSep 5, 2025
  If a button is functioning but fails to light up, such as the select button on your Konami Arcade Game Machine, the lamp wires may be disconnected from the button socket or reversely connected, or the button lamp (LED) may be defective. Reconnect the lamp wires to the socket. Check the performance on the 'I/O CHECK' screens. Replace the button as required.
G
Gary GoldenSep 7, 2025
What causes the rotating light to fail on Konami Mocap Boxing Arcade Game Machines?
- C
  Christopher RiceSep 7, 2025
  If the rotating light fails to light up or rotate on your Konami Arcade Game Machine, the rotating light lamp may be broken, or the rotating light control PCB may be in trouble. Replace the lamp with a new one of the same type. Immediately turn OFF the main power switch, unplug the power cord from the receptacle and contact your nearest dealer.
