6 Installation and assembling
6-1 Fastening the adjusters
n
How to fasten the cabinet adjusters
111mmmm1111111111
*Set the adjusters so that the casters do not touch the floor.
Take care not to exceed the maximum adjusting height of the adjuster.
*Make all the cabinet adjusters come in contact with the floor, tighten them
with hexagon nuts after making sure that the cabinet is placed in a
horizontal and stable position.
-Set
the adjusters in the order of
Steps 1 to
5
as shown in the
figure.
*When setting the adjusters in
step 5, refer to “6-2 Spreading
the foot sheet” on page 27.
on the front cabinet side
height: 70 mm
(2.76
ln)
26
