Simrad AP20 Autopilot
44 20220505H
Dimensions:............................... 160 mm x 126 mm (6.3 in x 5 in.)
Weight: ...................................... 0,9 kg including cable (2,0 lbs.)
Power consumption: .................. 0,9 watts
Temperature range:
Operation: ......................... 0 to +55 °C (+32 to + 130 °F)
Storage: ............................. –30 to +80 °C (–22 to +176 °F)
Environmental Protection:......... IP56
Mounting: .................................. Deck or bulkhead
Material:..................................... Black ABS
Figure 3-5 CDI35 Course Detector Interface - Dimensions
3.7 RF300 Rudder Feedback
Dimensions:............................... See Figure 3-6 and Figure 3-7.
Weight: ...................................... 0,5 kg (1,1 lbs)
Rudder angle:............................. ± 90 degrees
Output signal: ............................ Polarity independent frequency signal
Frequency resolution: ....... Centre: 3400 Hz, 20 Hz/degree of change
Linearity:........................... ± 3 degrees up to 45 degrees of rudder
Cable supplied: .......................... 10 m twisted pair shielded cable
Mounting: ................................. Horizontal, vertical, upside down
Material: .................................... Polyacetal (POM)
Environmental Protection:......... IP56
