C353/C253/C203 4-35
Troubleshooting
4
Decreased image quality may result if the surface of the image transfer belt or image transfer roller is
touched. Be careful not to touch the surface of the image transfer belt or the image transfer roller.
Be careful not to touch the film.
4.2.14 Clearing a paper misfeed in tray 2
!
Detail
For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 4-6.
1 Pull up the center right-side door release lever, and then
open the center right-side door.
2 Carefully remove any misfed paper.
transfer
belt
transfer
roller
To Next Page
