4
Troubleshooting
4-58 C353/C253/C203
4.3.2 Clearing jammed staples in the saddle stitcher
!
Detail
For details on clearing misfed paper in the finisher FS-519, refer to "Clearing a paper misfeed in finisher
FS-519" on page 4-44.
For details on clearing misfed paper in the saddle stitcher, refer to "Clearing a paper misfeed in the
saddle stitcher" on page 4-48.
1 Remove all paper from the finisher.
2 Raise the output tray, and then push down the staple
cartridge holder to remove it.
3 Raise the shutter of the staple cartridge holder, and then
remove one sheet of staples.
4 Return the shutter of the staple cartridge holder to its original position.
5 Insert the staple cartridge holder, and then push it up until
it locks into place.
6 Return the output tray to its original position.
To Next Page
