18
Controls
The basic system consists of the measuring device
and the protective holder.
The protective holder is used for calibration and to
store the measurement unit. Calibration is
performed inside the holder automatically at the
touch of a button. The gloss standard required for
this purpose is kept in the holder and is positioned
in such a manner that calibration is always
performed at the same point.
When the device is turned on inside the holder, it
performs a self-test (autodiagnosis).
If you will not be using the measuring unit, please
store it in the protective holder. In this way the
measurement optics are protected from dirt and
dust and the calibration standard is always readily
available.
The operate button and scroll wheel are used to
control the system. Pressing the wheel turns the
unit on and causes a menu to be displayed. All
settings within the menus are made by turning and
pressing the wheel.
Pressing the operate button starts measurements or
performs functions that are displayed. In addition,
you can return from the various menus to mode with
the operate button. System operation is supported
by an autodiagnosis test, comments and error
messages. Measurement values and comments
appear in the display.
