Korg M3 Owner's Manual

Menu Command Load selected
67
Media mode
Here we will explain only the menu commands “Load
RADIAS Formant Motions” and “Load a RADIAS Formant
Motion.”
For details on the other parameters and menu commands,
refer to “Media mode” in the M3 parameter guide. (☞M3
parameter guide p.389)
Menu Command
Load selected
11) Load RADIAS Formant Motions
All formant motion data from a .PCG file will be loaded.
1. To load the data, press the OK button. To cancel
without loading, press the Cancel button.
12) Load a RADIAS Formant Motion
Data for the selected formant motion will be loaded into the
number you specify.
1. If you wish to load a formant motion data other
than the one already selected, use “Formant
Motion” (upper line) to select the formant motion
data that you wish to load.
2. In “Formant Motion,” (lower line) select formant
motion data into which the data will be loaded.
3. To load the data, press the OK button. To cancel
without loading, press the Cancel button.

Korg M3 Specifications

General

Synthesis Type	EDS (Enhanced Definition Synthesis)
Sound Engine	EDS (Enhanced Definition Synthesis)
MIDI	In, Out, Thru
Keyboard	61-key, velocity-sensitive, aftertouch
Sequencer	16-track MIDI sequencer
Sampling	Open Sampling System
Display	TouchView graphical user interface with 320x240 color TFT LCD
Arpeggiator	2 polyphonic arpeggiators
Controllers	Joystick, Ribbon Controller
Outputs	L/MONO, R, Individual 1-4, Headphones
USB	Yes, USB MIDI
Storage	SD card slot
Combinations	1, 792 user combinations
Polyphony	120 voices (max)
Effects	5 Insert effects, 2 Master effects, 1 Total effect
