69
Appendices
EXB-RADIAS Specifications
Appearance and specifications of this product are subject to change without notice. (January/’07)
EXB-RADIAS (RADIAS synthesizer board)
System MMT (Multiple Modeling Technology)
Sound generator
Polyphony
24 voices
*The actual maximum polyphony will depend on the settings of the parameters that make up the
sound.
Synthesizer section
Oscillator
2 oscillators + noise generator
Oscillator 1: eight basic waveforms (Saw/Square/Tri/Sine/Formant/
Noise/DWGS/Audio In)
Four types of modulation (Waveform/Cross/Unison/VPM)
Oscillator 2: four basic waveforms (Saw/Square/Tri/Sine)
Two types of modulation (Ring/Sync)
Filter
Four types of filter routing (single, serial parallel, individual)
Two multi-mode filters per voice
Filter 1: Variable –24 dB LPF – –12 dB LPF – HPF – BPF – Thru
Filter 2: Switchable LPF/HPF/BPF/Comb
Driver/Wave shape
For each voice, one non-linear driver or wave shape (11 types) can be
inserted
EQ 3-band EQ (adjustable frequency for the mid-range)
Modulation
For each voice, three envelope generators, two LFOs, and three 16-step
modulation sequencers
Eight virtual patches
Envelope generators, LFOs, and the M3’s selectors can modulate major
parameters
Vocoder section
16-band vocoder (level and pan adjustable for each band)
Formant Motion function (sixteen sets of formant motion data can be recorded)
Formant Shift function, Formant Hold function
Structure
Program
Synth programs (synthesizer section)
Vocoder programs (synthesizer section + vocoder section)
128 preloaded (I-F bank)
I-F bank: dedicated RADIAS bank
U-A – U-G banks: assignable to EDS/RADIAS by bank
Combination, Sequencer
Up to four synth programs + vocoder section (maximum 16 timbres/tracks, can be combined with
EDS programs)
The M3’s effects, X–Y control, KARMA, drum track, and controllers etc. can be used in the same way as for the EDS system.
Audio input
Audio input
One stereo source can be routed from the M3’s audio input sources
The audio inputs AUDIO INPUT 1/2, S/P DIF L/R, and FireWire L/R (if the EXB-FW is installed) can be
input to the RADIAS oscillators or vocoder.
AUX bus
One stereo source from the M3’s AUX bus 1/2 or 3/4 can be routed.
The audio input following an insert effect, the drum track, or an EDS timbre etc. can be input to the
RADIAS oscillator or vocoder.
Included items Owner’s manual, screws
