PROG P4: Amp/EQ 4–8: EQ
37
Pickup: This simulates an electromagnetic pickup. Depth
adjusts the depth.
Note: The above illustration for Pickup shows differences in
the output waveform when a sine wave at C4 is input. The
transformation will vary depending on the input pitch.
Level Boost: Boosts the output level. Depth adjusts the
amount of boost.
This may produce high output volumes than other
wave shape types.
4–1b: Amp Level
Amp Level [000...127]
This controls the basic volume level of Oscillator 1, before
keyboard tracking, velocity, and other modulation.
Punch Level [000…127]
Creates a more “snappy” attack by adjusting the amount of
pulse waveform that is added to the oscillator output only
during the attack. Increasing this value will emphasize the
attack.
If the attack is slowed down by the EG etc., this will
have no effect.
Keyboard Track [–63…+63]
Specifies how keyboard tracking will affect the volume.
With positive (+) settings, the volume will increase as you
play upward from the C4 key, and decrease as you play
downward.
With negative (–) settings, the volume will decrease as you
play upward from the C4 key, and increase as you play
downward.
If this value is 0, keyboard tracking will not affect the
volume.
Note: Keyboard tracking works according to the pitch as
controlled by pitch bend, transpose, and modulation
sequencer. It does not reflect pitch changes produced by
vibrato or virtual patching.
4–1c: Pan
Pan [L000...C064...R127]
This controls the stereo pan of RADIAS oscillator. A setting
of L001 places the sound at the far left, C064 in the center,
and R127 to the far right.
4–8: EQ
Here you can make the Mid sweep EQ settings.
For details on the available parameters and menu
commands, please see “4–8: EQ” on page 65 of the M3
parameter guide.
Depth: 000
Depth: 064
Depth: 127
Depth: 000 Depth: 064
Depth: 127
