Korg PA4X User Manual

124| Connecting a video monitor
19 Connecting a video
monitor
You can connect Pa4X to a TV or video monitor, to read lyrics and chords
with your fellow musicians or audience.
Connect the external video monitor
▪ Use the VIDEO OUT connector to connect Pa4X to a TV set or video monitor.
Depending on the type of video monitor, you can use a cable of the RCA-to-
RCA type (if the monitor is equipped with a Video Composite input), or the
RCA-to-SCART type (if the monitor is equipped with a SCART connector).
You can buy the needed cables at a store that sells television equipment.
Go to the Video Out page
1 If it is off, turn the instrument on.
2 Go to the Global > Audio & Video > Video Out page.
Select the video standard
▪ Use the System menu to select the video standard.
System Meaning
PAL Used in most European, South American, Asian and African countries.
This setting can be also used with SECAM TV sets (used in France,
Russia, and some African countries); in this latter case, however, the pic-
ture is shown in black & white.
NTSC Used in North America, Central America and part of South America. It is
also used in Japan, Korea, Taiwan, Philippines and Burma.

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
