Korg PA4X User Manual

Turning the instrument on |19
03 Powering up
Turning the instrument on
Connecting the power adapter
Plug the supplied power cable into the POWER socket on the back of the
instrument, and the cable plug into a wall power socket.
When the cable is connected, the instrument is in standby.
Warning: When the instrument is in standby, it is still connected to the power line.
Accessing the inside of the instrument can be dangerous. To completely disconnect
the instrument from the power, unplug the power plug from the power socket on the
wall.
Turning the power on or off
Turn the instrument on
▪ Press the POWER (
) button to turn the instrument on (that is, ‘exit from
standby’). After you turn the instrument on, wait for the welcome screen to
disappear, then the main page of the Style Play mode will be shown in the
display.
Turn the instrument off (standby)
▪ Keep the POWER (
) button pressed for about one second, then release
it when the screen appears dimmed. The shutdown procedure will begin and
last for a few seconds. Please do not disconnect the power cable during this
procedure.

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
