Korg PA4X User Manual

Setting the Chord Recognition |69
09 Customizing the Styles
Setting the Chord Recognition
Choosing where to play chords (Chord Scan area)
You can play chords with your left or right hand separately, or with both
hands. You can choose the recognition area, depending on the song you are
playing and your preferred playing style.
The area where chords are recognized depends on the status of the CHORD
SCAN indicators.
CHORD SCAN Where to play chords (Chord Scan area) Notes to play
LOWER Left hand (Lower area of the keyboard) Depends on the
Chord Recognition
mode
UPPER Right hand (Upper area of the keyboard) Three or more
LOWER+UPPER Both hands (full keyboard) Three or more
Off No chord recognized –
Make chords be recognized when played with your left hand
▪ Press the CHORD SCAN > LOWER button to turn its indicator on.
Make chords be recognized when played with your right hand
▪ Press the CHORD SCAN > UPPER button to turn its indicator on.
Always play three or more notes to let the arranger recognize a chord.
Make chords be recognized when played with both hands
▪ Press both the CHORD SCAN (LOWER+UPPER) buttons to turn their indica-
tors on.
Always play three or more notes to let the arranger recognize a chord.

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
