Korg PA4X User Manual

Playing different Sounds with the left and right hand |45
Split, Keyboard modes, Sounds
When changing the SPLIT status, the number of Sounds you hear may
change.
SPLIT
indicator
Keyboard
mode
Left hand (Lower) Sounds Right hand (Upper) Sounds
Off Full No Lower Sound Up to three Upper Sounds as-
signed to the full extension of
the keyboard
On Split A single Lower Sound as-
signed to the left hand
Up to three Upper Sounds as-
signed to the right side of the
keyboard.
Changing the split point
You can choose a different point where the keyboard is split into an Upper
and a Lower part. This is called the split point.
Change the split point from the control panel
1 Keep the SPLIT button pressed to open the Split Point dialog.
2 Play the lowest note of the Upper (right hand) part on the keyboard.
Change the split point from the display
1 While in the Main page, touch the Split tab to see the Split pane.
2 Touch the keyboard diagram in the display, then play the lowest note of the
Upper (right) part on the keyboard.
As an alternative, touch the Split Point parameter to select it, and use the
VALUE controls to select the new split point.

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
