Korg PA4X User Manual

46| Customizing the Sound sets
Playing two or three Sounds at the same
time
Turning the Keyboard Sounds on or off
You can play up to three layered Sounds on the keyboard. This is useful to
add, for example, a layer of Strings or Synth Pads to the Grand Piano sound.
The Sounds will be assigned to the Upper part of the keyboard.
When the SPLIT button indicator is turned off (Full Keyboard mode), the
Upper parts will play on the full range of the keyboard, as it happens on an
acoustic piano. Otherwise (Split Keyboard mode), you will play the Upper
Sounds with the right hand.
Upper
Upper
Lower
Turn a Sound on or off from the control panel
▪ Use the ON/OFF buttons in the KEYBOARD SOUNDS section to turn the cor-
responding Sounds on or off.
Turn the selected Sound on of off from the display
▪ If the Sound you want to mute is in Play, touch the Play/Mute icon to set it
to Mute.
▪ If the Sound you want to hear is in Mute, touch the Play/Mute icon to set it
to Play.

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
