Korg PA4X User Manual

24| Interface basics
The user interface in detail
Display and user interface elements
Color TouchView graphical user interface
Pa4X features our exclusive easy-to-use TouchView™ graphic interface,
based on a touch panel LCD screen. By touching items on the LCD screen,
you can select pages, tabs, and parameters, and set parameter values via
on‐screen menus and buttons.
Operative modes
The pages of Pa4X are grouped in various operating modes. Each mode is
accessed by pressing the corresponding button in the MODE section on the
control panel.
Each operating mode is marked with a different color code, that helps you
understand where you are at first sight.
Two special modes (Global and Media) overlap the current operating mode,
that remains active in the background.
The Record mode can be accessed from the Style Play, Sequencer and Sound
modes, and allows for creating new Styles, Songs or Samples.
Edit menus and sections
Pages are grouped in sections, to be selected by touching the corresponding
buttons in the edit menu that opens up when you press the MENU button.

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
