Korg PA4X User Manual

44| Customizing the Sound sets
06 Customizing the Sound
sets
Playing different Sounds with the left and
right hand
Splitting the keyboard
Split the keyboard into a Lower (left hand) and Upper (right hand) part
▪ Press the SPLIT button on the control panel to light up its indicator. The
keyboard will be divided into a Lower (left hand) and Upper (right hand) part.
Upper
Lower
Remove the split and play the Upper Sounds over the full keyboard range
▪ Press the SPLIT button again to turn its indicator off. The Upper Sounds will
play on the full keyboard range, as in an acoustic piano.
Upper

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
