Korg PA4X User Manual

Overview of the instrument |9
Overview of the instrument
The following pages show the functional areas of the front and real panels.
Front panel
The front panel is where you can find the instrument’s controls, the (op-
tional) loudspeakers and the music stand.
KeyboardHeadphones
Guide for the music stand and
PaAS amplification system
PaAS amplification system
You can install the (optional) PaAS amplification system. When installed,
control the output volume of the speakers via the MASTER VOLUME knob.
The speakers are automatically deactivated when connecting the head-
phones. You can also manually deactivate them by deselecting the Speakers
checkbox in the Global > Audio & Video > MP3/Speakers page.

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
