Korg PA4X User Manual

Installing a microSD card |149
KORG Pa4X Features
Storage Hard Disk Drive
Pa4X-76: standard
Pa4X-61: optional, user installable; HDIK-3 hard disk installation
kit required
microSD card (card not included); rear panel slot with plastic
cover
USB external drives (drive not included); 1 front panel port, 1 rear
panel port
Display 7” Wide capacitive color TouchView™ TFT display
Clock Internal System Clock
Power Consumption 100-240 Volts, 50/60 Hz
< 0.5 Watt in standby / 16 Watt normal / 35 Watt with PaAS installed
Dimensions
(W x D x H)
Pa4X-76: 1,192 x 364.4 x 125.56 mm / 46.93” x 14.35” x 4.94”
Pa4X-61: 980 x 364.4 x 125.56 mm / 38.58” x 14.35” x 4.94”
(without music stand, display fully lowered)
Weight Pa4X-76: 16.3 kg / 35.93 lbs
Pa4X-61: 13.9 kg / 30.64 lbs
Accessories AC Power Cable, Music Stand, Quick Guide manual
Accessory Disc, containing the Video Manuals, additional manu-
als and software utilities
Options PaAS Amplication System
ST-SV1 BK Keyboard Stand
HDIK-3 Hard Disk Installation Kit (for Pa4X-61 only)
EC-5 Multiswitch Pedal
EXP-2 Foot Controller
XVP-10 Expression/Volume Pedal
DS-1H Damper Pedal (supports half-pedaling)
PS-1 Pedal Switch
PS-3 Pedal Switch
Specifications and appearance are subject to change without notice for im-
provement.

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
