Korg PA4X User Manual

Navigating through the pages |31
Navigating through the pages
Going to a page
Through this manual, page addresses are shown as in the following example:
Style Play > Mixer/Tuning > EQ Gain
Mode Edit section Page
Here is how the above works:
1 Press the STYLE PL AY button to go to the Style Play mode. When the in-
strument turns on, it is already in this mode (this the Main page of the Style
Play mode).
2 Press the MENU button on the control panel to see the edit menu of the
Style Play mode.

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
