Korg PA4X User Manual

Mixing the grouped Accompaniment Sounds |71
Mixing the grouped Accompaniment
Sounds
Grouped Accompaniment Sounds
As in a mixer, the Accompaniment Sounds can be grouped together. For
example, instead of separately muting the guitar and the strings parts in
the Accompaniment, you can mute the Accompaniment (ACCOMP) group
by touching a single button.
Grouped Accompaniment Sounds can be accessed directly from the Main
page > Volume pane:
Muting grouped Accompaniment parts
Turn a group of Accompaniment Sounds off (Mute)
▪ If the group you want to mute is in Play, touch the Play/Mute icon to set it
to Mute.
Turn a group of Accompaniment Sounds on (Play)
▪ If the group you want to hear is in Mute, touch the Play/Mute icon to set it
to Play.
Turning the individual Accompaniment Sounds on or off
Sounds can be muted, in case you don’t want to hear them in the mix. As an
example, the Accompaniment might contain a Piano part, and you want to
play it live on the keyboard.

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
