Korg PA4X User Manual

Reading the music score |95
Clef Meaning
Treble Standard Treble clef.
Treble+8 Treble clef with transposition one octave upper.
Treble-8 Treble clef with transposition one octave lower.
Bass Standard Bass clef.
Bass-8 Bass clef with transposition one octave lower.
Exit from the Score page
▪ When done with the score, press either the SCORE or the EXIT button.
Following the Song
You can always see where you are in the score by watching at these indica-
tors:
▪ A red vertical line, showing indicating the current staff in play.
▪ A red triangle, showing the current position.
Showing lyrics, chords, note names
Read the Lyrics
▪ Touch the Lyrics button to make the lyrics (if available) appear or disappear.
Read the chords
▪ Touch the Chord button to make the chord symbols (if available) appear or
disappear.
Read the note names
▪ Touch the Note button to make the note name appear or disappear next to
each note.
Choosing the chords and note names language
Chords and note names are shown either according to the English or Italian
system, depending on the selected language.
▪ Go to the Global > General Controls > Interface page, and use the Language
parameter to change the language.

Korg PA4X Specifications

General

Polyphony	128 voices
Type	Arranger Keyboard
USB	USB to Host, USB to Device
Keyboard	76 keys (PA4X-76) / 61 keys (PA4X-61), semi-weighted with velocity and aftertouch
Sound Engine	EDS-X (Enhanced Definition Synthesis – Expanded)
Display	7-inch TFT color touchscreen
Connectivity	MIDI In/Out/Thru, USB to Host, USB to Device
Dimensions	PA4X-61: 980 x 364.4 x 125.56 mm
Sounds	512 User Sounds
Sequencer	16-track sequencer
Audio Inputs	2 x 1/4" (line), 1 x XLR (mic)
Audio Outputs	Left/Right, Headphones, Sub 1/2
Storage	Internal SSD and microSD slot
Weight	PA4X-76: 16.3 kg / PA4X-61: 13.9 kg
