Korg Pa50 Service Manual

QA Full Inspection
Pa-50
7
In the list, "LED OFF" means that all LEDs are off. Please confirm if all LEDs are off.
Following cases are NG:
*Even if correspondent SW is pressed, test does not progress
*LED is not on when the LED should be on.
*LED is on when LED should NOT be on.
In the case of NG, please complete the test.
Correspondent List is followed.
After "SW/LED Inspection" Completion, please press [F3] to go to "LCD Inspection".

Korg Pa50 Specifications

General

Type	Arranger Keyboard
Polyphony	62 voices
User Styles	48
MIDI	In, Out, Thru
Keyboard	61 keys
Timbres	16
ROM	32 MB
Performances	160
Effects	4 stereo digital multi-effect systems
Sequencer	16-track
Song Play	Yes
Display	Backlit LCD
Outputs	L/Mono, R, headphones
Inputs	Damper Pedal, Assignable Pedal/Switch
Floppy Disk	3.5"
Storage	Internal and floppy disk
Connections	Sustain pedal, assignable pedal
Amplification	2 x 15 Watts
Speakers	2 x 10 cm
Sound Engine	HI (Hyper Integrated) Synthesis System
