Korg Pa50 Service Manual

Page: 7/12
5-8 Assignable SW/Pedal Operation Inspetion
Check if Style performs automatically on PEDAL ON and it stops on PEDAL OFF.
NOTE: When you are in MODE/STYLE, performance starts as soon as Pedal is connected.
So, Pedal should be connected before poweron
5-9 Connect Sound Source (such as CD Player) to LINE IN and check if Pa50's speakers
works correctly.
5-10 Insert FDD in which SMF file data is written into FDD and check if SMF file is performed
correctly.
Î [MODE/SONG] key ON
Î Insert FDD
Î Press [BASS/PERC] key among Volume Value Keys
Î Press [F-2] key
Î Press [ENTER/YES] ("Wait" is displayed)
Î Confirm if "KA02-010" is displayed on LCD (KA02-010 is SMF name)
Î Press [SEQUENCER1 PLAY/STOP] key to start.
Î After confirmation if performance is correct (about 10 measures), Press Press
[SEQUENCER1 PLAY/STOP] key to stop
STOP Performance
Extract FD from FDD without Failure
Power Off
CAUSTION!
Do not pass Pa50 to next process with FD inserted. Management of the number of FD is always needed.

Korg Pa50 Specifications

General

Type	Arranger Keyboard
Polyphony	62 voices
User Styles	48
MIDI	In, Out, Thru
Keyboard	61 keys
Timbres	16
ROM	32 MB
Performances	160
Effects	4 stereo digital multi-effect systems
Sequencer	16-track
Song Play	Yes
Display	Backlit LCD
Outputs	L/Mono, R, headphones
Inputs	Damper Pedal, Assignable Pedal/Switch
Floppy Disk	3.5"
Storage	Internal and floppy disk
Connections	Sustain pedal, assignable pedal
Amplification	2 x 15 Watts
Speakers	2 x 10 cm
Sound Engine	HI (Hyper Integrated) Synthesis System
