Korg Pa50 Service Manual

QA Full Inspection
Pa-50
20
<PERFORMANCE CHECK>
MIDI THRU, MIDI Clock and Performance Inspection.
After Power on, confirm if Pa50 performs correctly. Following is the method of MIDI THRU and MIDI
Clock Inspection. Please send "Program Change" from Pa50 to MIDI Equipment and Inspect.
1. MODE [PROGRAM] SW on.
2. PROGRAM [PIANO] SW on.
3. ]LOWER/ACC5] SW on
After completion, please check if Pa50 works properly.
After confirmation, please press [STYLE] first, then [START/STOP] and confirm Demo Song is played
correctly.
After confirmation of PA50 operation, this inspection completes. Please make power off and take cables
and Floppy disk out of Pa50.

Korg Pa50 Specifications

General

Type	Arranger Keyboard
Polyphony	62 voices
User Styles	48
MIDI	In, Out, Thru
Keyboard	61 keys
Timbres	16
ROM	32 MB
Performances	160
Effects	4 stereo digital multi-effect systems
Sequencer	16-track
Song Play	Yes
Display	Backlit LCD
Outputs	L/Mono, R, headphones
Inputs	Damper Pedal, Assignable Pedal/Switch
Floppy Disk	3.5"
Storage	Internal and floppy disk
Connections	Sustain pedal, assignable pedal
Amplification	2 x 15 Watts
Speakers	2 x 10 cm
Sound Engine	HI (Hyper Integrated) Synthesis System
