Korg Pa50 Service Manual

Page: 11/12
DISPLAY
Correspondent SW Correspondent LED ON/LED OFF
Ending1 ENDING [1] ENDING [1]
Ending2 ENDING [2] ENDING [2]
Intro1 INTRO [1] INTRO [1]
Intro2 INTRO [2] INTRO [2]
StartStop [START/STOP] [START/STOP] (RED)
Synchro SYNCHRO [START] SYNCHRO [START]
TapTempo TAP TEMPO SYNCHRO [STOP]
Write [WRITE] [WRITE]
Ensemble [ENSEMBLE] [ENSEMBLE]
Pad1 PAD[1] LED OFF
Pad2 PAD[2] LED OFF
Pad3 PAD[3] LED OFF
Pad4 PAD[4] LED OFF
PadStop PAD[STOP] LED OFF
Transp b TRANSPOSE[b] LED OFF
Transp # TRANSPOSE[#] LED OFF
Octave - OCTAVE [-] LED OFF
Octave + OCTAVE [+] LED OFF
Record [RECORD] [RECORD]
Menu [MENU] LED OFF
DrumPerc [DRUM-PERC] LED OFF
Drum [DRUM] LED OFF
Bass BASS/PERC [BASS] LED OFF
Perc BASS/PERC [PERC] LED OFF
Acc ACC/BASS [ACC] LED OFF
Bass ACC/BASS [BASS] LED OFF
-- -/ACC1 [-] LED OFF
Acc1 -/ACC1 [ACC1] LED OFF

Korg Pa50 Specifications

General

Type	Arranger Keyboard
Polyphony	62 voices
User Styles	48
MIDI	In, Out, Thru
Keyboard	61 keys
Timbres	16
ROM	32 MB
Performances	160
Effects	4 stereo digital multi-effect systems
Sequencer	16-track
Song Play	Yes
Display	Backlit LCD
Outputs	L/Mono, R, headphones
Inputs	Damper Pedal, Assignable Pedal/Switch
Floppy Disk	3.5"
Storage	Internal and floppy disk
Connections	Sustain pedal, assignable pedal
Amplification	2 x 15 Watts
Speakers	2 x 10 cm
Sound Engine	HI (Hyper Integrated) Synthesis System
