Korg Trinity Parameter Guide

5–1: Track Edit
103
5–1C: Event Edit
This allows you to edit individual events of recorded musical data.
a) Select the index that you wish to edit.
You can also directly press the LCD at the desired event, or use the scroll bar located at the
right.
At this time, selecting a Note event will cause it to sound.
b) If you modify the Location value, the event will move within the measure.
1 In the tab 1 display, select the desired track and Start Measure.
If you have set Track to MTR, continue to
4 .
2 When this command is selected, a dialog box shown at
right will appear.
3 Make settings in Set Event Filt to select the type of musi-
cal data that can be viewed (and edited) in the event edit
display.
The following types of data can be selected; Note, Pitch
Bend, Control Change, Program Change, After Touch,
and Poly After Touch. Types of data for which the check
box is checked will be shown in the event edit display
below.
4 To move to the event display press the OK button. To return to the previous display press the
Cancel button. If you press the OK key, the following dialog box will appear.
q
Step time =
q
Step time =
q
Step time =
Tie key
Press
Press
h
q
&
Press E and C Release E (continue holding C)
Press G
q
Release
a
b: location in the measure
(beat, clock)
Measure
Index no.
c: musical data

Korg Trinity Specifications

General

Timbrality	16 parts
Oscillators	2 per voice
LFO	2 per voice
MIDI	In, Out, Thru
Year Released	1995
Type	Workstation
Polyphony	32 voices
Keyboard	61 keys (velocity and aftertouch sensitive)
Effects	Master effects, Insert effects
Sequencer	16-track
Display	TouchView graphical user interface
Filter	Resonant low-pass, high-pass, band-pass
Memory	8 MB internal PCM ROM
Outputs	4 individual outputs, 1 stereo output
Inputs	2 audio inputs
Storage	3.5" floppy disk drive
Weight	15 kg
