Korg Trinity Parameter Guide

3–3: Velocity Zone (Track 1–8)
96
3–3: Velocity Zone (Track 1–8)
3–4: Velocity Zone (Track 9–16)
Here you can set the Top/Bottom Velocity to specify the range of velocities that will sound each
track 1–8, and set the Top/Bottom Slope to specify the range in which the volume will change.
The LCD will show a line to indicate the range of velocities which will sound each track, and the
area of the slope will be greyed.
If two or more tracks receiving the same channel are set so that their velocity ranges do not over-
lap, you can play different sounds with notes of different playing strengths. (Velocity Switch)
If the slopes (the greyed portions) overlap, the sounds will overlap, and the mix of the sounds will
change as you vary your playing strength. (Velocity Crossfade)
These settings have no effect on MIDI transmission or reception. All incoming note messages will
be recorded, and all notes played by the sequencer or on the keyboard will be transmitted.
It is not possible to set the Bottom Velocity above the Top Velocity. Nor is it possible to make
settings that would cause the Top Slope and Bottom Slope to overlap.
3–3a: Top Velocity [1…127]
Specifies the highest velocity value which will sound each track.
3–3b: Top Slope [0…120]
Specifies the range of velocities over which the volume will reach the original volume from the
Top Velocity.
This is not effective for the timbres that use Bank M programs.
With a setting of 0, the note will sound at the original volume for the Top Velocity.
With a setting of 120, the volume will decrease as the Top Velocity is approached.
3–3c: Bottom Slope [0…120]
Specifies the range of velocities over which the volume will reach the original volume from the
Bottom Velocity.
This is not effective for the timbres that use Bank M programs.
With a setting of 0, the note will sound at the original volume for the Bottom Velocity.
With a setting of 120, the volume will decrease as the Bottom Velocity is approached.
Page Menu
Track No.
3–3a
3–3b
3–3c
3–3d
Track 16
Track 1
3–3A
3–3B
3–3C
3–3D
Velocity Zone display
Information for
the selected
track

Korg Trinity Specifications

General

Timbrality	16 parts
Oscillators	2 per voice
LFO	2 per voice
MIDI	In, Out, Thru
Year Released	1995
Type	Workstation
Polyphony	32 voices
Keyboard	61 keys (velocity and aftertouch sensitive)
Effects	Master effects, Insert effects
Sequencer	16-track
Display	TouchView graphical user interface
Filter	Resonant low-pass, high-pass, band-pass
Memory	8 MB internal PCM ROM
Outputs	4 individual outputs, 1 stereo output
Inputs	2 audio inputs
Storage	3.5" floppy disk drive
Weight	15 kg
