5–1: Amp 1 Mod (Amplifier 1 Modulation)
40
Program Edit P5
The TRINITY series provides two amps; amp 1 for oscillator 1, and amp 2 for oscillator 2.
5–1: Amp 1 Mod (Amplifier 1 Modulation)
Here you can make settings for the volume of oscillator 1 and how it will change.
5–1a: Amplifier Level [0…127]
Sets the volume of oscillator 1.
5–1b: Amplifier Modulation
Specifies how the volume of oscillator 1 will be affected by Keyboard Tracking, Velocity, After-
touch, and Alternate Modulation.
Amplifier Keyboard Tracking
The following Key and Ramp parameters specify how keyboard position will affect the volume
(refer to the diagram on the following page).
Key (Keyboard Tracking Keys)
Specify the note numbers at which keyboard tracking will begin to apply. Keyboard tracking will
not affect the volume of the notes between Low and High.
• Low (Low Key) [C–1…G9]
Keyboard tracking can be specified for the range below the specified note number.
Note numbers can also be input from the keyboard. For details refer to Basic Guide page 8 “5. Set-
ting a parameter”.
• High (High Key) [C–1…G9]
Keyboard tracking will apply to the range above the specified note number.
Note numbers can also be input from the keyboard. For details refer to Basic Guide page 8 “5. Set-
ting a parameter”.
Ramp (Ramp settings)
Specify the angles of the keyboard tracking.
• Low (Lower Ramp) [–99…+99]
With positive (+) settings, playing below the specified Low note number (Keyboard Track Key)
will produce progressively louder levels, and with negative (–) settings will produce progressively
quieter levels.
5–1a
5–1b
5–1c
Page Menu
5–1A
5–1B
5–1C
To Next Page
